Automatic bottle shrink sleeve wrapping machine with bottle arrangement function

Home

Products

Shrink Wrapper

Automatic bottle shrink sleeve wrapping machine with bottle arrangement function

Product Item：UXF-6030ALT

Machinery Test Report	Provided
Video outgoing-inspection	Provided
Warranty of core components	1 Year
Core Components	PLC, Motor
Type	Wrapping Machine
Condition	New
Application	Food, Beverage, Commodity, Medical, Chemical, Machinery & Hardware, APPAREL, Textiles
Automatic Grade	Automatic
Voltage	380v
Brand Name	UCPACK
Dimension(L*W*H)	L 1820 mm x W 2100 mm x H 2150 mm
Certification	CE
Model	UXF-6030ALT
Pack Size Max.	H<300mm
Sealing Bar	650mm
Load Capacity Max.	30kg
Efficiency	0-1

Product Detail
FAQs

Automatic bottle shrink sleeve wrapping machine with bottle arrangement function.

This kind shrink wrapping machine is mainly packing bottles. And arrange bottles 3*4, 2*6, 2*3, 4*6 automatically. Full-auto one machine will pack 12 packages per minute. Cutter size, even tunnel size can be customized.

Model	UXF-6030ALT	Note
Pack Size Max.	L+H ≤ 600 mm; W ≤ 400 mm; H ≤ 300 mm;	Can be customized
Sealing Bar	650 mm	Can be customized
Worktable Height	750mm with 50mm adjustable feet	Can be customized
Load Capacity Max.	30kg	/
Efficiency	0-15 pcs/min	/
Infeed Conveyor	L=1500mm, Left/Right side	/
Lane	Std. 4 lanes (Optional) × 4 rows (Optional)	Can be customized
Film	PE shrink film in 40-120um thickness	/
Air Supply	0.5-0.7Mpa	/
Voltage	AC220V 1ph 50/60Hz	Can be customized
Power	2.5kw	/
Machine Size	L 1820mm × W 2100mm × H 2150mm	/
Machine Weight	240kg	/
Options	• Lengthen Sealing Bar; • Increased Packing Height; • Number of Lanes × Rows; • Infeed and Outlet Conveyor
