Automatic Flap Folding Box Case Carton Cover Tape Sealer Machine

Product Item：UFX-5050Z

Core Components	PLC, Motor
Type	Wrapping Machine
Condition	New
Application	Food, Beverage, Commodity, Chemical, Machinery & Hardware, APPAREL, Textiles
Automatic Grade	Automatic
Voltage	AC220V 1ph 50/60Hz
Brand Name	UCPACK
Dimension(L*W*H)	L1780 * W930 * H1600mm
Certification	CE Certification
Pack Size Max.	L Unlimited *W 500 mm*H 500 mm
Pack Size Min.	L 150 mm * W 120 mm * H150 mm
Conveyor Speed	20 m/min
Driven	Right And Left Twin Side Belts Drive
Transport Package	Plywood Seaworth

Product Description

UFX-5050Z Automatic Carton Sealing Machine with Top Fold Flaps.UFX-5050Z automatic carton sealer machine with both side drive in the form of pneumatic folding lid, trapezoidal screw the width of high and low adjusting mechanism, the structure design of the high strength makes the machine has reliable performance and can be adapted to production line continuous heavy sealing work. It is suitable for packing and sealing of products in various industries such as household appliances, textile, food, daily provisions, medicine, light industry, chemical industry and so on.

Specifications

Model	UFX-5050Z
Max. Packing Size	L Unlimited W 500 mmH 500 mm
Min. Packing Size	L 150 mm * W 120 mm * H150 mm
Conveyor Speed	20 m/min
Drive Type	Left and Right Twin Side Belts Drive
Worktable Height	600 mm - 750 mm adjustable
Tape Width	48 / 60 / 75 mm
Voltage	220 VAC 1 ph 50/60 Hz
Power	480 W
Machine Size	L 1780W 930 H 1600 mm (Without Infeed and Outlet Roller Extension Tables)
Machine Weight	180kg

Features

Control panel; Power switch, running light,start,emergency stop Tape roll mechanism Folding carton cover part Automatically Auctomatical carton sealer working with carton erector Total apckaging project; Carton erector, conveyor,carton sealer
